Name: SS400 Carbon Steel Plate Sheet
SKU: 0

Request a Quote

Carbon Steel Plate/Sheet



Location： HOME > CARBON STEEL > Carbon Steel Plate/Sheet > SS400 Carbon Steel Plate Sheet

SS400 Carbon Steel Plate Sheet

Available Carbon Steel Grades:SS400,For more material grades, Please click

Payment Term:TT,L/C,etc

Price Term:Ex-Work,FOB,CNF,CFR,etc

MOQ:1Ton

Delivery Time:Usually 7-30days, or upon negotiation

Loading Port:TIANJIN,SHANGHAI,DALIAN ,QINGDAO,etc

If you have any questions, please feel free to contact us.

8618961806236

sale2@ybtmetalproducts.com

Request a Quote

PRODUCT DESCRIPTION

SS 400 STEEL PLATE SPECIFICATION

Item : SS400 steel plate/sheet for general purpose structural steels
Thickness : 5mm-150mm
Width : 1000mm-4500mm
Length : 3000mm-18000mm

SS400 STEEL PLATE EQUIVALENT GRADES

SS400 JIS3101	Comparison of Steel Grades
	EN10025:1990	FE 360 B
	DIN17100	ST37-2
	NFA 35-501	E24-2
	EN 10025-2	S235JR
	ASTM	A283C
	UNI7070	FE 360 B

SS400 CHEMICAL COMPOSITION

Grade	C	Si	Mn	P	S
SS400	-	-	-	0.050 max.	0.050 max.

SS400 MATERIAL PROPERTIES

Grade		Fe	Si	C	S	P
SS400	min.	99.25	–	–	–	–
SS400	max.	100	0.4	0.26	0.050	0.040

SS400 MECHANICAL PROPERTIES

Grade	Yield Strength min. (Mpa)		Tensile Strength (Mpa)	Elongation min. %			ImpactResistancemin.[J]
	Thickness ＜16 mm	Thickness ≥16mm		Thickness	Thickness	Thickness
				＜5mm	5-16mm	≥16mm
SS400	245	235	400-510	21	17	21	–

PHYSICAL PROPERTIES: OF SS400 COLD ROLLED PLATE

Density and specific gravity, g/cm3	7.85
melting point, ℃	1494-1527
Specific heat capacity, J/(Kg·K)	473 at 20 ℃
Electrical resistivity, μΩ·m	About 0,15 (20 ℃)
Long. elastic modulus, GPa	206
Tr. modulus of elasticity, GPa	79
Shear modulus, GPa	79
Thermal conductivity, (W/m·K)	57-60
Linear expansion coefficient, (10-6/K)	11.3-11.6 (20 ℃)
Young’s modulus, GPa	206
Poisson’s ratio	0.3
Magnetic permeability, mm2/s	13.9

SS400 HOT ROLLED PLATES THICKNESS CHART

SS400 Steel Plate Thickness in mm.
1.2	1.4	1.6	1.8	2.0	2.3	2.5	(2.6)	2.8
(2.9)	3.2	3.6	4.0	4.5	5.0	5.6	6.0	6.3
7.0	8.0	9.0	10.0	11.0	12.0	12.7	13.0	14.0
15.0	16.0	(17.0)	18.0	19.0	20.0	22.0	25.0	25.4
28.0	(30.0)	32.0	36.0	38.0	40.0	45.0	50.0

TOLERANCE OF SS400 PLATESS

Material thickness tolerance in mm
Thickness (t)	Steel Plate width (W)<1600	1600≤ W <2000	2000≤ W <2500	2500≤ W <3150	3150≤ W <4000	4000≤ W <5000
4.00≤t<5.00	±0.45	±0.55	±0.55	±0.65	–	–
5.00≤t<6.30	±0.50	±0.60	±0.60	±0.75	±0.75	±0.85
6.30≤t<10.00	±0.55	±0.65	±0.65	±0.80	±0.80	±0.90
10.00≤t<16.00	±0.55	±0.65	±0.65	±0.80	±0.80	±1.00
16.00≤t<25.00	±0.65	±0.75	±0.75	±0.95	±0.95	±1.10
25.00≤t<40.00	±0.70	±0.80	±0.80	±1.00	±1.00	±1.20
40.00≤t<63.00	±0.80	±0.95	±0.95	±1.10	±1.10	±1.30
63.00≤t<100.00	±0.90	±1.10	±1.10	±1.30	±1.30	±1.50
100.00≤t<160.00	±1.30	±1.50	±1.50	±1.70	±1.70	±1.90
160.00≤t<200.00	±1.60	±1.80	±1.80	±1.90	±1.90	±2.10
200.00≤t<250.00	±1.80	±1.90	±1.90	±2.00	±2.00	±2.20
250.00≤t<300.00	±2.00	±2.10	±2.10	±2.20	±2.20	±2.50
300.00≤t≤350.00	±2.10	±2.30	±2.30	±2.40	±2.40	±2.80

WIDTH OF SS400B PLATES

Standard width of steel plate and steel belt (mm)
600	630	670	710	750	800	850	900	914	950
1000	1060	1100	1120	1180	1200	1219	1250	1300	1320
1400	1500	1524	1600	1700	1800	1829	1900	2000	2100
2134	2438	2500	2600	2800	3000	3048

SS400 PROPERTIES

Grade	Yield Strength min. (Mpa)		Tensile Strength (Mpa)	Elongation min. %			Impact Resistance min.[J]
SS400	Thickness <16mm	Thickness ≥ 16mm	400-510	Thickness <5mm	Thickness 5-16mm	Thickness ≥ 16mm	-
SS400	245	235	400-510	21	17	21	-

Conquest Steel and Alloys Also Distribute Other Types of SS400 Plate Namely :

SS400 CS Plates, SS 400 Steel Plates, SS400 Plates, MS SS 400 Plates, SS400 Steel Plates Exporter, SS400 Steel Plates Supplier in China, SS400 Plates, SS400 Hot Rolled Steel Plates, SS400 HR Plates Stockist, Low Carbon Steel SS400 Plates, Low Alloy Steel SS400 Plate, Mild Steel SS400 Plates, SS400 MS Plate, HR SS400 Steel Plates Exporter in China, Carbon SS400 Hot Rolled Plates, SS400 Carbon Steel HR Plates, SS400 Structural Low Carbon Plates, SS 400 Structural Low Carbon Plates, SS400 Carbon Steel and Low Alloy Steel Plates, SS400 Carbon Structural Plates, SS 400 Steel Plates In China, SS400 Carbon Plates, SS400 Steel Plate Based in China.

CARBON STEEL PRODUCT DETAILS

STAINLESS STEEL PRODUCT DETAILS

ALLOY STEEL PRODUCT DETAILS

WAREHOUSE

FAQ

Q: How do you control quality?

A : Mill Test Certification is supplied with shipment, Third Party Inspection isavailable.and we also get ISO,SGS,Alibaba Verified.

Q : What are the advantages of your company?

A : We have many professionals,technical personnel, more competitiveprices and best after-dales service than other steel companies.

Q : What extra services do you offer?

A : We can provide you with roll splitting, size cutting, surface treatment(galvanizing, coating and sandblasting) and other services according toyour requirements.

Q: How can l get a quotation?

A : Kindly provide us your details request (item No, style, logo, size, material, surface treatment, quantity etc.) the more detailed the better, leave us an inquiry or email to us and we will response promptly!

Q : How to get a free sample?

A : We can provide our existing similar samples for free to check the style and quality! For sample with your own logo or design, mold fee will be charged base on specification.

Q : What's the payment method?

A : It is very convenient And TT,LC...are all available.

Q : What's the process of order?

A : Send us Inquiry →get quotation → payment done →open mold and make samples →deliver you samples or send you pictures of samples for approval → mass production.

Q : When can l expect the customized product to be finished?

A : Sample:7-10 working days (Standard).Bulk order: 10-25 working days (Standard). If you have any other questions, please feel free to contact us!
